WyreStorm CON-H2-SCL

An essential tool when mixing 4K & 2K screens on the same distribution system, the CON-H2-SCL enables in-line scaling of HDMI content. An HDMI signal from a source device, DA or matrix is converted so that it can be accepted by the connected display. Via a powerful scaling chip, 4K/60 4:4:4 or 4:2:0 can be down-scaled to as low as 480P; likewise, content can be up-scaled to 4K/60 4:4:4. Set up & configuration is done using a simple PC tool which is part of WyreStorm Management Suite V1.6. The software tool allows management of the scaling function and EDID via a simple interface.

IN-LINE EDID EMULATOR

In a legacy installation scenario where EDID is not being communicated properly, the CON-H2-EDID can be connected in-line after the source device and using either a built-in or uploaded EDID file, can ensure the correct content is requested from the source.

4K SCALING IN ANY DIRECTION

Whether the requirement is to scale to or from the full capacity of HDMI2.0, the CON-H2-SCL allows incoming content to be converted (stripping HDR metadata if necessary) to a format compatible with the connected display or projector.

AUDIO DE-EMBED

Connected source devices or switchers that are sending 2ch PCM can have the audio de-embedded from the CON-H2-SCL via the Toslink port for connection to an external audio system.

HDMI2.0 MAXED OUT

Sporting an 18Gbps HDMI input, the CON-H2-SCL can support all UHD video signals up to and including 2160p 4:4:4/60, and high frame-rate HDR 12bit 4:2:2 up to 60Hz.

5 YEAR WARRANTY

This WyreStorm Pro AV product comes with a 5 Year Warranty.
